MSV
MSV Limitless 60/72/96/120V 220V 50A MPPT Solar Charge Controller SMU With On-Grid Companion Feature
₹ 16,650 / Piece
₹ 21,999
24%
You will earn 167 points from this product
- Genuine Quality
- Free Shipping
- Secure Checkout
Companion Feature for PM SURYA GHAR YOJNA OnGrid Systems
MSV Limitless MPPT Series
Unlock the full potential of your solar energy system with the MSV Limitless MPPT Series – ODL-MPPT-SMU 60/72/96/120 220/50, a next-generation Maximum Power Point Tracking (MPPT) Solar Management Unit engineered for superior performance, flexibility, and long-term reliability.
⚡ Unmatched Power & Efficiency
220V Open Circuit solar input and deliver an impressive 50A charging output to your battery bank. The high-speed MPPT algorithm ensures maximum power harvest from every solar panel, improving system efficiency by up to 30% compared to traditional PWM controllers.
🔋 Wide Voltage & Battery Compatibility
Designed for 60V, 72V, 96V and 120V systems, supports multiple battery chemistries:
Lead-Acid (LA)
Lithium-Ion (Li-ion)
Lithium Iron Phosphate (LiFePO₄) or LFP
Smart multi-stage charging—including Pre-conditioning, Bulk (CC), Absorption (CV), and Float—ensures longer battery life and optimal charge utilization.
⚙️ Smart Configurability & Control
User-configurable output voltage & current
Selectable power management modes:
SOL → BAT → GRID
SOL → GRID → BAT
Grid Charging Always ON
Grid Charging Always OFF
These intelligent configurations maximize uptime and energy efficiency across diverse residential, commercial, and hybrid setups.
🛠️ Built for Durability & Ease of Use
Housed in a robust, thermally-optimized enclosure, this controller is engineered for reliable operation under harsh environmental conditions. Its intuitive interface and plug-and-play wiring simplify installation and system integration.
MSV Limitless MPPT Series
Unlock the full potential of your solar energy system with the MSV Limitless MPPT Series a next-generation Maximum Power Point Tracking (MPPT) Solar Management Unit engineered for superior performance, flexibility, and long-term reliability.
🌞 Advanced MPPT Solar Management
A real-time MPPT tracking engine, ensuring fast response to changing irradiance and temperature. This guarantees stable, high-efficiency operation even in dynamic or partially shaded conditions.
🌍 Sustainable Performance You Can Trust
Reduce your dependency on grid power, minimize electricity costs, and contribute to a cleaner environment. The MSV Limitless MPPT Series delivers high-efficiency solar power conversion, ensuring maximum return on investment and sustainable energy independence.
Model No.
ODL-MPPT-SMU-60/72/96/120-220/50
Technology
MPPT
Product Series
MSV OD Limitless Series (ODL)
Battery Operating Mode
69/72/96/120V Battery
Solar Panel Support (Pmax)
4000W on 60V Battery
5000W on 72V Battery
6000W on 96V Battery
7500W on 120V Battery
Solar Input Voltage (VOC)
220V
Battery Type
Lead- Acid, Lithium Ion, Lithium PO4 battery
Output Current (Max)
50A (User Configurable from 5A to 50A)
Charging Stages
Preconditioning, Bulk (CC), Absorption (CV), Float
Protections
Solar Reverse, Reverse Battery (Fuse Based), Over Current , Over Voltage, Over Temperature Protection, Solar Reverse Current flow
Cooling
Double Fan Based Adaptable forced air Cooling
Display
16x2 Character Display
Parameters Displayed on LCD
Solar Voltage (Vsol), Solar Current (Isol), Solar Power (Sol PWR), Battery Voltage (Vbat), Charging Current (Ichg), Solar Panel Generated Unit, Power Save ON/OFF, Mains Connect/ Disconnect
Switching Element
MOSFET
Efficiency
Up to 95%
Mounting Type
Wall Mounted
Product Dimensions (L*W*H)
34x18x14 CM
Weight
4.9 KG
Warranty
2 Years
Country Of Origin
Bharat
Bharat
