Eastman Sunbridge 3KW 48V Solar Hybrid Inverter IP65 10 Years Warranty
- Genuine Quality
- Free Shipping
- Secure Checkout
Out of Stock
The Eastman Solar Hybrid Inverter (IP65) - available from 3kW to 5kW - is purpose-built for India's demanding power environment. Designed to withstand extreme heat, dust, humidity and monsoon conditions, its IP65-rated enclosure ensures all-weather reliability. It intelligently manages solar PV, battery bank and grid (DISCOM) making it ideal for frequent power cuts and voltage fluctuations common across Indian households and shops. It prioritizes solar self-consumption, reduces electricity bills during peak tariff hours and switches to backup mode in under 10 ms during Power Outages - ensuring uninterrupted power for critical appliances like fans, pumps and refrigerators. It also comes with remote monitoring through the Eastman ONE App, ensuring you can monitor your Solar Energy System from anywhere.
Why Choose Eastman Solar Hybrid
Inverter IP65 (Low Voltage)?
Max Charging/DiSCharging Current
Battery Charges fast and gives back every bit
of stored power when you need it
Connect up to 10 units in Parallel
Need more Capacity? Just add on Inverters - no need to remove or replace What you already have
Type II SPD Enabled AC and DC side
Keeps System remains protected from lightning and grid spikes - from both Solar Side & Grid Side.
Delivering Full Power at LOW Voltage
Produces power from early morning to late evening — giving more hours of free electricity every day.
Double MPPT - Two Independent Maximum Power Point Trackers (MPPT)
More electricity from every corner of your roof Shading on one side does not affect the Other and keeps the system protected, even if one tracker has a problem.
Maximum PV Input
Allowing more panels per string - less cabling. lower installation cost and higher system efficiency
Grid Safe a Compliant
iTHD | Fully Grid complian
Superior Efficiency
97.6% Efficiency Maximum Solar Harves
Subsidy Secured
100% Eligible for PM Suryaghar Yojana up to Rs 78,OO
Tough & Compact
(Dust & Rain Proof) -No Enclosure Needed I Install Anwahere
Perfect Power Factor
Power Factor 1.0 100% Productive Energy
Best Suited For
- Homes experiencing frequent Cuts
- Commercial Shops and showrooms
- Clinics, Offices, and educational institutes
- Solar retrofits and capacity expansions
- Anyone seeking a dependable Hybrid Power System
| Model | ESHY.3KW.L.1P |
| AC LOAD OUTPUT | |
| Rated Output Power KW | 3 |
| Maximum Continous Power KVA | 3.3 |
| Rated AC Output Current | 13.7A |
| Max. AC Output Current | 15A |
| Phase | Single Phase |
| Output Voltage | 220/230V |
| Switch Time (ms) | 10 Normal and UPS mode |
| Wave Form | Pure Sine Wave |
| Power Factor | 1 (Adjustable) |
| Voltage THD (%) | <3 |
| PV INPUT | |
| MPPT Efficiency | >99% |
| Max PV Input Power | 4500W |
| MPPT Voltage Range | 90V – 500V |
| Normal Voltage | 360V |
| Max. PV Input Current A | 18.5 |
| No. of MPPT/PV Strings | 2 |
| Inverter Technology | MPPT |
| BATTERY | |
| Battery Normal Voltage DC | 51.2V |
| Battery Voltage Range | 40-60V |
| Max. Charging Current (DC/AC) | 80A |
| Max. Discharging Current (DC) | 80A |
| Battery Support | Lithium PO₄ & Lead-acid |
| PROTECTION | |
| PV Reverse polarity Protection | Yes |
| Over Current/Voltage Protection | Yes |
| Anti-Islanding Protection | Yes |
| AC Short Circuit Protection | Yes |
| Residual Current Detection | Yes |
| Ground Fault Monitoring | Yes |
| Insulation Resistor Detection | Yes |
| PV Arc Detection | Yes |
| Enclosure Protect level | IP65 / NEMA4X |
| Mounting Type | Wall Bracket |
| GENERAL DATA | |
| Transformer Type | Transformerless |
| Remote Monitoring | WiFi optional (Built-in/External) |
| Display | LCD+LED |
| Cooling | Natural Convection |
| Stand by Consumption | <10W |
| Relatively Humidity | 0-100% |
| Communication Interface | RS485 |
| Operating Temperature Range | -25 to 60°C |
| Noise | <25 dB |
| Monitor Mode | LCD, LED, RS485, Wi-Fi. (optional), 4G (optional) |
| Weight | 18 KG |
| Product Dimensions (L*W*H) in cm | 37*51.3*19.2 |
| Warranty | 10 Years* Warranty |
| Country of Origin | India |
| Manufacturer | Eastman Auto & Power Ltd. Corporate Office: Quattro Towers, Plot No. 249E, Udyog Vihar Phase IV, Gurugram, Haryana-122016, India I support@eaplworld.com I 78728 78728 |
Note:- 25 Sq. mm Battery Connecteing Lead 1+1 Meter included with this inverter without any extra cost.
