Eastman Sunbridge 3KW 48V Solar Hybrid Inverter IP65 10 Years Warranty

₹83,700 / Piece

₹1,10,740

24%

Whatsapp
Facebook
You will earn 837 points from this product

  • Genuine Quality
  • Free Shipping
  • Secure Checkout
Out of Stock

The Eastman Solar Hybrid Inverter (IP65) - available from 3kW to 5kW - is purpose-built for India's demanding power environment. Designed to withstand extreme heat, dust, humidity and monsoon conditions, its IP65-rated enclosure ensures all-weather reliability. It intelligently manages solar PV, battery bank and grid (DISCOM) making it ideal for frequent power cuts and voltage fluctuations  common across Indian households and shops. It prioritizes solar self-consumption, reduces electricity bills during peak tariff hours and switches to backup mode in under 10 ms during Power Outages - ensuring uninterrupted power for critical appliances like fans, pumps and refrigerators. It also comes with remote monitoring through the Eastman ONE App, ensuring you can monitor your Solar Energy System from anywhere.

Why Choose Eastman Solar Hybrid
Inverter IP65 (Low Voltage)?

Max Charging/DiSCharging Current
Battery Charges fast and gives back every bit
of stored power when you need it

Connect up to 10 units in Parallel
Need more Capacity? Just add on Inverters - no need to remove or replace What you already have

Type II SPD Enabled AC and DC side
Keeps System remains protected from lightning and grid spikes - from both Solar Side & Grid Side.

Delivering Full Power at LOW Voltage
Produces power from early morning to late evening — giving more hours of free electricity every day.

Double MPPT - Two Independent Maximum Power Point Trackers (MPPT)
More electricity from every corner of your roof Shading on one side does not affect the Other and keeps the system protected, even if one tracker has a problem.

Maximum PV Input
Allowing more panels per string - less cabling. lower installation cost and higher system efficiency

Grid Safe a Compliant
iTHD | Fully Grid complian

Superior Efficiency
97.6% Efficiency Maximum Solar Harves

Subsidy Secured
100% Eligible for PM Suryaghar Yojana up to Rs 78,OO

Tough & Compact
(Dust & Rain Proof) -No Enclosure Needed I Install Anwahere

Perfect Power Factor
Power Factor 1.0 100% Productive Energy

Best Suited For

  • Homes experiencing frequent Cuts
  • Commercial Shops and showrooms
  • Clinics, Offices, and educational institutes
  • Solar retrofits and capacity expansions
  • Anyone seeking a dependable Hybrid Power System
Model ESHY.3KW.L.1P
AC LOAD OUTPUT
Rated Output Power KW 3
Maximum Continous Power KVA 3.3
Rated AC Output Current  13.7A
Max. AC Output Current  15A
Phase Single Phase
Output Voltage 220/230V
Switch Time (ms) 10 Normal and UPS mode
Wave Form Pure Sine Wave
Power Factor 1 (Adjustable)
Voltage THD (%) <3

PV INPUT
MPPT Efficiency >99%
Max PV Input Power 4500W
MPPT Voltage Range 90V – 500V
Normal Voltage 360V
Max. PV Input Current A 18.5
No. of MPPT/PV Strings 2
Inverter Technology MPPT

BATTERY
Battery Normal Voltage DC 51.2V
Battery Voltage Range 40-60V
Max. Charging Current (DC/AC) 80A
Max. Discharging Current (DC) 80A
Battery Support Lithium PO₄ & Lead-acid

PROTECTION
PV Reverse polarity Protection Yes
Over Current/Voltage Protection Yes
Anti-Islanding Protection Yes
AC Short Circuit Protection  Yes
Residual Current Detection Yes
Ground Fault Monitoring Yes
Insulation Resistor Detection Yes
PV Arc Detection Yes
Enclosure Protect level IP65 / NEMA4X
Mounting Type Wall Bracket

GENERAL DATA
Transformer Type Transformerless
Remote Monitoring WiFi optional (Built-in/External)
Display LCD+LED
Cooling Natural Convection
Stand by Consumption <10W
Relatively Humidity 0-100%
Communication Interface RS485
Operating Temperature Range -25 to 60°C
Noise <25 dB
Monitor Mode LCD, LED, RS485, Wi-Fi. (optional), 4G (optional)
Weight 18 KG
Product Dimensions (L*W*H) in cm 37*51.3*19.2
Warranty 10 Years* Warranty
Country of Origin India
Manufacturer ​Eastman Auto & Power Ltd.
Corporate Office: Quattro Towers, Plot No. 249E, Udyog Vihar Phase IV, Gurugram,
Haryana-122016, India I support@eaplworld.com I 78728 78728

Note:- 25 Sq. mm Battery Connecteing Lead 1+1 Meter included with this inverter without any extra cost.
